New Zoom Triple Camera EO/IR Target Locking 5KM Distance Measurement,Target Location Calculating,4.08MP HD

Product Categories

HongKong GLK Industrial Co., Limited

Contact Now

Brand Name : GL

Model Number : GL-Triple

Certification : CE

Place of Origin : China

MOQ : 1Set

Price : FOB

Payment Terms : TT

Supply Ability : 300Sets/Week

Delivery Time : 5Days

Packaging Details : Portable Hard Case

Weight : 900g

EO;IR : Yes Integrated

EO : 10*Zoom

Pixel : 4.08MP HD

IR : 19mm 640*480

Calculating : Target Location Calculating

Target Locking : EO/IR Target Locking Yes

Video : 128G HD Video

Distance Measurement : 5Km

Compatible With : DJI and Other Open Source Mavlink Protocol

Contact Now

New Zoom Triple Camera EO/IR Target Locking 5KM Distance Measurement,Target Location Calculating,4.08MP HD

Detailed Specifications :

*10Zoom EO Specifications**
Image Sensor	1/3’ Progressive Scanning CMOS
Effective Pixels	4.08MP
Video Output(HD)	1080P/60
Lens	Auto;Manual;priority mode(shutter/aperture)
	f=3.2-33.6
	F1.8-3.4
*640480 19mm IR Specifications**
Uncooled Spectrum Range	8μm ~ 14μm Thermal Imager
Detector Resolution	640*480
Pixel Spacing	17μm
Palette	White Thermal；Black Thermal；Seudocolor
Electric Zoom	1; 3
Temperature Measurement	Temperature Bar(Seudocolor Display)Highest Temperature;Lowest Temperature;Central Point Temperature
Video Resolution	1920*1080@60p/50/30p/25p
Datas Refresh Rate	25HZ
Targeting Rate	±32Pixel/Frame
Target Dimension	1616—128128
Laser Distance Measurement 5KM
